Код |
Внутр. Ø рукава |
Ø трубы |
m |
L1 |
СН1 |
PN |
||
|
DN |
DASH |
Дюйм |
||||||
|
2201203 |
5 |
-3 |
3/16 |
6L |
12x1,5 |
19,5 |
12 |
315 |
|
2231403 |
5 |
-3 |
3/16 |
6S |
14x1,5 |
23,5 |
14 |
415 |
|
2201403 |
5 |
-3 |
3/16 |
8L |
14x1,5 |
20,5 |
14 |
315 |
|
2231603 |
5 |
-3 |
3/16 |
8S |
16x1,5 |
25,5 |
17 |
415 |
|
2201204 |
6 |
-4 |
1/4 |
6L |
12x1,5 |
20,5 |
14 |
315 |
|
2231404 |
6 |
-4 |
1/4 |
6S |
14x1,5 |
23,5 |
14 |
450 |
|
2201404 |
6 |
-4 |
1/4 |
8L |
14x1,5 |
20,5 |
14 |
315 |
|
2231604 |
6 |
-4 |
1/4 |
8S |
16x1,5 |
25,5 |
17 |
450 |
|
2201604 |
6 |
-4 |
1/4 |
10L |
16x1,5 |
21,5 |
17 |
315 |
|
2231804 |
6 |
-4 |
1/4 |
10S |
18x1,5 |
25,5 |
19 |
450 |
|
2201804 |
6 |
-4 |
1/4 |
12L |
18x1,5 |
22,5 |
19 |
315 |
|
2232004 |
6 |
-4 |
1/4 |
12S |
20x1,5 |
2 7,5 |
22 |
450 |
|
2201605 |
8 |
-5 |
5/16 |
10L |
16x1,5 |
22 |
17 |
315 |
|
2231805 |
8 |
-5 |
5/16 |
10S |
18x1,5 |
26 |
19 |
350 |
|
2201805 |
8 |
-5 |
5/16 |
12L |
18x1,5 |
23 |
19 |
315 |
|
2232005 |
8 |
-5 |
5/16 |
12S |
20x1,5 |
28 |
22 |
350 |
|
2201606 |
10 |
-6 |
3/8 |
10L |
16x1,5 |
23 |
19 |
315 |
|
2201806 |
10 |
-6 |
3/8 |
12L |
18x1,5 |
23 |
19 |
315 |
|
2232006 |
10 |
-6 |
3/8 |
12S |
20x1,5 |
28 |
22 |
445 |
|
2232206 |
10 |
-6 |
3/8 |
14S |
22x1,5 |
30 |
24 |
445 |
|
2202206 |
10 |
-6 |
3/8 |
15L |
22x1,5 |
24 |
24 |
315 |
|
2232208 |
12 |
-8 |
1/2 |
14S |
22x1,5 |
30 |
24 |
415 |
|
2202208 |
12 |
-8 |
1/2 |
15L |
22x1,5 |
24 |
24 |
315 |
|
2232408 |
12 |
-8 |
1/2 |
16S |
24x1,5 |
30 |
27 |
400 |
|
2202608 |
12 |
-8 |
1/2 |
18L |
26x1,5 |
25 |
27 |
315 |
|
2202610 |
16 |
-10 |
5/8 |
18L |
26x1,5 |
25,5 |
27 |
315 |
|
2233010 |
16 |
-10 |
5/8 |
20S |
30x2 |
34,5 |
32 |
350 |
|
2203010 |
16 |
-10 |
5/8 |
22L |
30x2 |
25,5 |
27 |
315 |
|
2202612 |
19 |
-12 |
3/4 |
18L |
26x1,5 |
28 |
32 |
315 |
|
2233012 |
19 |
-12 |
3/4 |
20S |
30x2 |
35 |
32 |
350 |
|
2203012 |
19 |
-12 |
3/4 |
22L |
30x2 |
28 |
32 |
160 |
|
2233612 |
19 |
-12 |
3/4 |
25S |
36x2 |
39 |
41 |
350 |
|
2233616 |
25 |
-16 |
1 |
25S |
36x2 |
40 |
41 |
280 |
|
2203616 |
25 |
-16 |
1 |
28L |
36x2 |
30 |
41 |
160 |
|
2234216 |
25 |
-16 |
1 |
30S |
42x2 |
42 |
46 |
280 |
|
2234220 |
31 |
-20 |
11/4 |
30S |
42x2 |
42 |
46 |
280 |
|
2204520 |
31 |
-20 |
11/4 |
35L |
45x2 |
34 |
46 |
160 |
|
2235220 |
31 |
-20 |
11/4 |
38S |
52x2 |
48 |
55 |
210 |
|
2205224 |
38 |
-24 |
11/2 |
42L |
52x2 |
37 |
55 |
160 |
|
2235224 |
38 |
-24 |
11/2 |
38S |
52x2 |
48 |
55 |
210 |
